AXIS T90D35 White LED Illuminator (01217-001)
[shortdesc]High-performance white-light LED illuminator with selectable illumination angles, PoE or AC/DC power options, IP66/IK09 environmental protection, and included beam-angle lenses.[/shortdesc]
[properties]
| Model | AXIS T90D35 W-LED Illuminator (01217-001) |
| Compatible products | All Axis network cameras |
| Type | 6000 K white LED |
| Luminous power | 3727 lm |
| Dimensions | 135 × 180 × 68 mm (5 × 7 × 3 in) |
| Cable length | 2.5 m (8.2 ft) |
| Weight | 1.65 kg (3.61 lb) |
| Casing | Aluminum and polycarbonate, white and silver |
| Environment | Indoor and outdoor |
| Operating temperature | −50 °C to 50 °C (−58 °F to 122 °F) |
| Humidity | 10–100% RH (condensing) |
| Storage temperature | −50 °C to 70 °C (−58 °F to 158 °F) |
| Mounting | Wall, ceiling, pole, fixed box camera housing |
| Security / Impact protection | IK09 |
| Ingress protection | IP66 |
| Certifications (EMC) | FCC Part 15.107 & 15.109 Class B, ICES-003 Issue 6 Class B, EN 55032 Class B, RCM AS/NZS CISPR 32 Class B, VCCI Class B, EN 55015, EN 55024, EN 50130–4, EN 61547 |
| Certifications (Safety) | IEC/EN 60598-1, IEC/EN 62471 (risk group 2), C22.2 No 250.0–08, UL 2108, UL 8750 |
[/properties]
[specifications]
| Beam angles (without lenses) | 10° × 10° |
| Beam angles (with included lenses) | 35° × 10°, 60° × 25°, 80° × 30° |
| Beam angles (optional) | 120° × 50° |
| Illumination distance (10° × 10°) | 180 m (591 ft) |
| Illumination distance (35° × 10°) | 95 m (312 ft) |
| Illumination distance (60° × 25°) | 50 m (164 ft) |
| Illumination distance (80° × 30°) | 35 m (115 ft) |
| Illumination distance (120° × 50°, optional) | 25 m (82 ft) |
| Control technology (AC/DC variant) | Push-button or remote control: power level, photocell sensitivity, telemetry link for remote activation, timer |
| Control technology (PoE variant) | Push-button or remote control: power level, photocell sensitivity, timer |
| Power input (AC/DC) | 12–24 V AC/DC, 50–60 Hz |
| Max power (AC/DC) | 42 W |
| Standby (AC/DC) | 0.3 W |
| Power input (PoE) | High-Power PoE, max 60 W |
| Max power (PoE) | 47 W |
| Standby (PoE) | 4.5 W |
| Display / Indicators | Indicator LEDs |
[/specifications]
[accesories]
| Included | Three diverging lenses (35°, 60°, 80°), IP66 cable coupler (PoE variant only) |
| Optional accessories | AXIS T90B Remote Control, AXIS WL Diverging Lens C 120°, AXIS T90 Wall-and-Pole Mount, AXIS T90 Single Bracket, AXIS T90 Multi Bracket, AXIS T8134 60 W Midspan, AXIS T8124-E Outdoor Midspan 60 W 1-port, AXIS T8125 AC 24 V Midspan 60 W 1-port, AXIS T8144 60 W Industrial Midspan, AXIS T8504-E Outdoor PoE Network Switch, Mains adaptor PS-24, Power Supply PS24 240 W |
[/accesories]
AXIS T90D35 W-LED is engineered to provide strong, uniform white-light illumination tuned for professional surveillance. Its modular lens system allows installers to match illumination spread with the camera’s field of view and deployment distance, minimizing light wastage and improving scene clarity. With rugged environmental protection and power-efficient LED performance, it ensures reliable operation in challenging climates and demanding security environments.
Available in both PoE and AC/DC variants, the illuminator’s control interface enables efficient management of power levels, photocell sensitivity, and timed activation for optimized energy use.
Optimized Long-Range White-Light Illumination for Professional Surveillance
- Interchangeable beam-angle lenses for precise illumination control
- Power-efficient 6000 K LEDs delivering up to 3727 lumens
- PoE or AC/DC power flexibility to fit existing infrastructure
- Extreme temperature resilience from −50 °C to 50 °C (−58 °F to 122 °F)
- IK09 and IP66 construction for harsh outdoor environments
- Remote adjustments for photocell sensitivity, power level, and timing
Ideal Use Cases
- Perimeter and fence-line surveillance
- Industrial and logistics yards
- Parking facilities and access control points
- High-security government, defence, and critical-asset monitoring
Technical Specifications Summary
- Illumination angle: 10° × 10°, 35° × 10°, 60° × 25°, 80° × 30°, optional 120° × 50°
- Illumination distance: up to 180 m (591 ft) depending on lens
- LED color temperature: 6000 K white light
- Luminous power: 3727 lm
- Power options: 12–24 V AC/DC or High-Power PoE (60 W)
- Environmental protection: IP66, IK09
- Operating range: −50 °C to 50 °C (−58 °F to 122 °F)
Upgrade Your Operations
Enhance nighttime visibility with precision-engineered white-light illumination.
