AXIS T90D25 W-LED (01215-001)
[shortdesc]High-performance white-light LED illuminator with flexible beam angles, selectable AC/DC or PoE powering, and durable IP66/IK09 outdoor protection optimized for Axis cameras.[/shortdesc]
[properties]
| Model | AXIS T90D25 W-LED (01215-001) |
| Product Type | White-light LED illuminator |
| Compatible Products | All Axis network cameras |
| Illumination Distance | Up to 110 m (361 ft) with 10° × 10° lens |
| Casing | Aluminum and polycarbonate |
| Color | White and silver |
| Mounting | Wall, ceiling, pole, fixed box camera housing |
| Operating Conditions | -50°C to 50°C (-58°F to 122°F) |
| Humidity | 10–100% RH (condensing) |
| Storage Conditions | -50°C to 70°C (-58°F to 158°F) |
| Dimensions | 100 × 135 × 66 mm (4 × 5 × 2.5 in) |
| Cable Length | 2.5 m (8.2 ft) |
| Weight | 950 g (2.11 lb) |
| Environmental Rating | IP66 & IK09 |
| EMC Approvals | FCC Part 15.107 and 15.109 Class B, ICES-003 Issue 6 Class B, EN 55032 Class B, RCM AS/NZS CISPR 32 Class B, VCCI Class B, EN 55015, EN 55024, EN 50130–4, EN 61547 |
| Safety Certifications | IEC/EN 60598-1, IEC/EN 62471 (risk group 2), C22.2 No 250.0-08, UL 2108, UL 8750 |
[/properties]
[specifications]
| Models | AC/DC variant, PoE variant |
| Illumination Output | White-light 6000K, 1863 lm |
| Beam Angles (interchangeable lenses) | 10°, 35°, 60°, 80°, 120° |
| Distances by Lens | 10° × 10° = 110 m (361 ft); 35° × 10° = 65 m (213 ft); 60° × 25° = 35 m (115 ft); 80° × 30° = 25 m (82 ft); 120° × 50° = 18 m (59 ft) |
| AC/DC Power Input | 12–24 V AC/DC, 50–60 Hz, 24 W max, 0.3 W standby |
| PoE Power Input | IEEE 802.3at Type 2 Class 4, 25 W max, 4.5 W standby |
| Control (AC/DC) | Buttons or remote control: power level, photocell sensitivity, telemetry link (remote activation), timer |
| Control (PoE) | Buttons or remote control: power level, photocell sensitivity, timer |
| Environment Use | Indoor & outdoor |
| Display & Indicators | Status LEDs |
[/specifications]
[accesories]
| Included | Three diverging lenses (35°, 60°, 80°); IP66 cable coupler (PoE variant only) |
| Optional accessories | AXIS T90B Remote Control; AXIS WL Diverging Lens B 120°; AXIS T90 Wall-and-Pole Mount; AXIS T90 Single Bracket; AXIS T90 Multi Bracket; AXIS T8123-E Outdoor Midspan 30 W; AXIS T8133 Midspan 30 W; AXIS T81B22 DC 30 W Midspan; AXIS T8134 60 W Midspan; AXIS T8124-E Outdoor Midspan 60 W; AXIS T8125 AC 24 V Midspan 60 W; AXIS T8144 60 W Industrial Midspan; AXIS T8508/T8516/T8524 PoE+ Switches; AXIS T8504-E Outdoor PoE Switch; Mains Adaptor PS-24; Power Supply PS24 240 W |
[/accesories]
The AXIS T90D25 W-LED delivers powerful, efficient wide-spectrum illumination for video surveillance, ensuring excellent visibility in low-light environments using optimized LED distribution. Its flexible lens system allows fine-tuning of coverage to match the exact field of view of the camera, minimizing foreground overexposure and supporting longer detection distances.
With options for either AC/DC or PoE powering, plus remote control adjustment, the T90D25 integrates seamlessly into existing installations and enables easy on-site or remote configuration. Built with rugged IP66/IK09 environmental protection, it delivers reliable performance in harsh outdoor conditions, from -50°C to +50°C.
Precision illumination with durable and flexible power options
- Optimized LED output for improved clarity and visibility in dark environments
- Interchangeable beam lenses provide tailored illumination angles from 10° to 120°
- Choice of AC/DC or PoE input enables flexible deployment
- Rugged IP66 and IK09 durability ensures reliable outdoor performance
- Remote control capability for power and sensitivity adjustment
- Supports ALL Axis network cameras
Ideal Use Cases
- Critical perimeter and fence-line monitoring
- Parking lots, industrial zones, loading bays
- Public security & municipal surveillance
- Warehouse yards & outdoor commercial sites
- Any location requiring bright visual identification at night
Technical Specifications Summary
- Illumination: White-light 6000K, 1863 lm
- Lens angles: 10°, 35°, 60°, 80°, 120°
- Max illumination range: 110 m (361 ft)
- Power (AC/DC): 12–24 V AC/DC; 24 W max
- Power (PoE): IEEE 802.3at Class 4; 25 W max
- Operating temperature: -50°C to 50°C (-58°F to 122°F)
- Environmental protection: IP66, IK09
- Mounting options: Wall, ceiling, pole, housing
Upgrade Your Operations
Enhance night-time surveillance performance with optimized high-power illumination.
